Wide Range of Applications
Removable insulation jacket can be used in different fields; such as breweries, beverage factories, food factories, chemical factories, pharmaceutical factories, ships, industrial robots and so on.
Removable thermal insulation jacket (industrial thermal insulation jacket) which is more widely used is the reaction kettle thermal insulation jacket, electric accompanied by heat (electric heating) thermal insulation jacket, shipyard (ship valve) thermal insulation jacket, injection molding machine (gun barrel) thermal insulation jacket/cover, manhole, heterogeneous thermal insulation jacket and so on.
Thermal Insulation Performance Comparison
| Project | Aerogel detachable |
|---|---|
| Texture |
Outer protective layer: silicone composite fireproof cloth (fireproof, waterproof, oil proof, acid and alkali resistant, corrosion resistant)
Intermediate insulation layer: nano aerogel + glass fiber felt (nano aerogel is the best insulation effect at present, considering the cost, the combination of the two has achieved the best insulation effect.) Non-toxic and asbestos-free.
Lining: silicone composite fireproof cloth/high silica cloth (maximum temperature resistance of 600 degrees, strong oxidation resistance)
|
| Thickness | According to the equipment temperature of 25-30mm, there is room for pipeline layout or later transformation |
| Heat Conductivity Coefficient | 0.017~0.023w/m·k (for heat insulation, the smaller the thermal conductivity, the better) |
| Construction |
1. Disassembly and installation are very convenient, reusable, and do not require professional assistance.
2. For a 100 square meter insulation area calculated with 6 workers: removal takes 2 hours, installation takes 1 working day. Maintenance equipment can be disassembled in sections at any time.
|
| Environmental Suitability | Strong adaptability: acid and alkali resistance, clean and aesthetic appearance, and the surface can be easily scrubbed. |
| Environmental Protection | No pollution, completely free of asbestos and any other harmful substances. |
| Range of Application | Strong flexibility, non-standard equipment can be customized, offering a wide range of application scenarios. |
| Energy Conservation | More than 30% energy saving compared with traditional thermal insulation materials. |
| Payback Time | Long service life: 20 years indoors, 15 years outdoors. Investment costs can be recovered within one year. One investment, many years of returns. |
| Cost of Investment | The one-time investment cost is about 20-30% more than traditional insulation. |
Frequently Asked Questions (FAQ)
1. What are the typical application fields for removable insulation jackets?
They are widely utilized across breweries, beverage plants, food processing facilities, chemical plants, pharmaceutical factories, shipyards, and industrial robotics. Common equipment includes reaction kettles, electric heating systems, ship valves, injection molding barrels, and manholes.
2. What material structure makes up the aerogel detachable jacket?
It comprises a three-layer composite: an outer silicone composite fireproof cloth, an intermediate core of nano aerogel combined with glass fiber felt for optimal thermal barrier properties, and an inner lining of high-temperature silica/silicone cloth resisting up to 600°C.
3. How much energy can be saved compared to traditional insulation?
Aerogel removable insulation delivers more than 30% higher energy efficiency over conventional insulation materials due to its exceptionally low thermal conductivity (0.017~0.023 W/m·k).
4. Is professional labor required for installation and maintenance?
No specialized technical team is required. The modular design allows straightforward assembly and disassembly, enabling segmented removal during equipment maintenance and rapid re-installation.
5. What is the expected service life and return on investment (ROI)?
The jackets feature a service life of up to 20 years indoors and 15 years outdoors. Due to significant energy conservation, the initial investment is typically fully recouped within one year.
6. Are these insulation covers environmentally safe and compliant?
Yes, they are 100% free of asbestos, non-toxic, generate no secondary pollution, and offer strong chemical resistance against acid and alkali environments.
